JV080044 – Stainless Steel Ball Lift Check Valve (Non-Return) Valve

JV080044 – Stainless Steel Ball Lift Check Valve (Non-Return) Valve

A simple and economical standard ball check (non-return) valve that has very low cracking pressures and pressure drops suitable for a wide range of applications.

Product Options
Clear
Add to quote
SKU: N/A Categories: , , ,

Description

Type
Standard Ball Lift
Size & Connections
DN50 to DN150 • PN16 Flange
Duty
Air • Inert Gas • Oil • Water
Materials
Stainless Steel Body • NBR Coated Aluminium Ball (50mm: Viton Coated)
Pressure Rating
16 Bar
Temperature
-10°C to 80°C (50mm: -10°C to 220°C)

Additional information

Variant

DN 50, DN 65, DN 80, DN 100, DN 125, DN 150, Other – Please specify in message
